Vacuum Pump
Oil-lubricated reciprocating vacuum pumps engineered for deep, stable vacuum in pharmaceutical, chemical, medical, and packaging processes. Heavy cast-iron construction for long, low-maintenance, continuous-duty service.
Built to Perform
Every component is engineered for reliability in continuous industrial operation.
Reciprocating oil-lubricated design
Deep, stable ultimate vacuum
Heavy cast iron construction
Low noise and vibration
Continuous-duty rated
Engineered for reliable performance
Parth Vacuum Pumps use proven reciprocating piston technology to draw down and hold a deep, stable vacuum reliably, hour after hour. The rugged cast-iron build, efficient air cooling, and simple serviceability make them a dependable choice wherever a clean, consistent vacuum is critical — from pharmaceutical and chemical processing to medical, laboratory, and vacuum-packaging applications.
Technical Specifications
Detailed configuration data for engineering evaluation.
- Motor Range
- 1 – 20 HP
- Ultimate Vacuum
- Up to 700 mmHg
- Free Air Displacement
- 30 – 500 M³/H
- Type
- Oil-lubricated reciprocating
- Cooling
- Air-cooled
- Duty
- Continuous
* Specifications are indicative. Contact us for custom configurations.
Model Comparison
Find the right capacity for your application.
| Model | Piston Displacement | Max. Vacuum (HG) | Motor H.P. | No. of CYL. | ||
|---|---|---|---|---|---|---|
| CFM | M3/H | MM | INCH | |||
| PE 15/1 SV | 6.78 | 11.49 | 635.0 | 25.00 | 1.5 | 1 |
| PE 30 SV | 18.0 | 30.50 | 736.6 | 29.00 | 1.5 | 2 |
| PE 30 TV | 9.0 | 15.25 | 751.8 | 29.60 | 1.5 | 2 |
| PE 75 SV | 32.0 | 54.23 | 736.6 | 29.00 | 2.0/3.0 | 2 |
| PE 75 TV | 16.0 | 27.11 | 753.1 | 29.60 | 2.0/3.0 | 2 |
| PE 100 SV | 60.0 | 101.69 | 736.6 | 29.00 | 5.0 | 2 |
| PW 100 TV | 30.0 | 50.85 | 754.4 | 29.70 | 5.0 | 2 |
| PE 125 SV | 99.0 | 167.80 | 736.6 | 29.00 | 7.5 | 2 |
| PE 125 TV | 49.5 | 83.90 | 753.1 | 29.65 | 7.5 | 2 |
| PE 200 SV | 133.0 | 225.00 | 741.7 | 29.20 | 10 | 3 |
| PE 200 TV | 88.6 | 150.00 | 753.1 | 29.65 | 10 | 3 |
How a Vacuum Pump Works
The pump evacuates air from a sealed system, drawing down and holding a deep, stable vacuum.
Intake
Air is drawn from the sealed process or chamber.
Compression
The piston reduces the trapped volume, lowering system pressure.
Exhaust
The evacuated air is discharged out of the pump.
Deep Vacuum
The target vacuum level is reached and held steady.
Where It Works
Trusted across India's manufacturing sectors.
Pharmaceutical processing
Chemical & process industries
Medical & laboratory
Vacuum packaging & forming
Food processing
