Air Cooled After Cooler
Cools hot compressed air after compression to condense moisture before it enters the dryer. Finned tube design with high-efficiency cooling for extended downstream equipment life.
Built to Perform
Every component is engineered for reliability in continuous industrial operation.
Finned tube heat exchanger
High cooling efficiency
Low pressure drop
Compact design
Engineered for reliable performance
Air Cooled After Coolers reduce the temperature of compressed air immediately after compression. By cooling the air and condensing moisture, they protect dryers, filters, and downstream equipment from heat and water damage.
Technical Specifications
Detailed configuration data for engineering evaluation.
- Flow Rate
- 20 – 500 CFM
- Inlet Temperature
- Up to 180°C
- Outlet Temperature
- Ambient + 10°C
- Working Pressure
- Up to 16 kg/cm²
- Cooling
- Air-cooled (fan)
- Material
- Copper tubes / Aluminium fins
* Specifications are indicative. Contact us for custom configurations.
How an After Cooler Works
Cools hot discharge air right after the compressor and removes the first moisture.
Hot Air In
Hot air leaves the compressor discharge.
Air-Cooled Core
A fan-cooled heat exchanger drops the temperature.
Condensation
Cooling condenses out bulk moisture.
Separation & Drain
Condensate is separated and drained away.
Cooled Air Out
Cooler, drier air moves down the line.
Where It Works
Trusted across India's manufacturing sectors.
Pre-dryer cooling
Moisture condensation
Protecting downstream filters
High-temperature inlet systems
